Sunricher DALI DT8 RGBW Four Channel Professional 24v 96W DALI Driver
This DALI 4 channel driver is available from our extensive range of DALI lighting control systems from our Sunricher control device products. DALI (stands for digital addressable lighting interface) is an LED lighting management system with many control options for your lighting systems.
This DALI DT8 four-channel 24V 96W constant voltage RGBW Driver is a perfect addition to your DALI control system. The unit is a UL, ENEC and TUV-approved device which supports all DALI DT8 device commands. Colour control is as defined in the DALI specification for device type 8.
All the RGBW output channels of this device are controlled by a single DALI address. The DALI LED driver is compatible with universal DALI master controllers that support DT8 commands
DT8 commands enable easy RGBW colour adjustment and the DALI address can be manually assigned and displayed using the user interface and digital display if required. You can also configure the dimmer using the DALI system software tool and DALI USB interface.
This RGBW LED driver has a four-channel 24v DC constant voltage output and a 100v to 240v AC universal input. The driver features a high Power factor of over 0.9 making the efficiency greater than 90. The 4 channel driver also has smooth dimming to 0.1% without any flickering, running silently with no buzz when dimming.
LED Technologies supply a wide range of DALI devices such as DALI remote controllers, DALI BUS power supplies and LED Strip lights that are suitable to be controlled by our DALI 4-channel LED drivers and controllers.
For more information on this product, don't hesitate to get in touch with our sales team. Call, email or use our online live chat to talk to our technical sales team.
Shop our range of LED Controls through our website or contact our technical sales team.
Key Features:
RGBW DALI DT8 96w Driver
Constant voltage PWM controller
Compatible with DALI DT8 protocols
For RGBW LED lighting products
Enables dimming & colour adjustment
Configurable by DALI USB interface
For 24v RGBW LED products
Digital DALI address indicator
Installation Guide:
