    Diffuse Reflections Lens Tunable White LED Module - Linear Modules with 6 LEDs - 24V - 20-Pack

    $56.99
      (8 Reviews) | Write a review

    Part Number:GYKJLENS-CCT-X6-24V
    Add to Wishlist
    Choose options above to see availability
    checkmark

    Free Shipping

    No minimum purchase required.
    checkmark

    Worry-free Returns

    - 30 day return policy

    Diffuse Reflective CCT LED light modules are ideal for advertising light boxes, soft film ceilings because it emits even and spotless light. Each set of modular lights contains 20 light panels, with six 3030 LED chips on each panel. Each chip is equipped with an optical lens to reflect and refract the light multiple times, making the light bright and even to illuminate the whole space. LED light modules feature 175 degrees beam angle, which can effectively eliminate dark areas in the lighting by simply arranging the distance between the modules.
    This set of modular lights supports cutting each panel individually, making it suitable for mounting in a shaped light box. You can use the connectors to connect the cut sections of the module back to the power supply.  The wire length between each pair of modules is 20cm/ 7.87in.
    Using an aluminum substrate as its base material, the Diffuse Module Light features excellent heat dissipation, extending the life of the LED chips. Modular LED lights have an adjustable color temperature from 2700k to 6500k. You can use DALI dimmable driver to adjust the brightness and color temperature.
    A 24V power supply is required when using this diffuse reflective lens LED Module Light.

    Features
    1. 20pcs/string, every peice has 6 3030 LED beads.
    2. Can be cut every peice, which is flexible for adapting to irregular lightboxes.
    3. The wire length between modules is 20cm/ 7.87in.
    4. The PCB size is 70mm*70mm.
    5. The beam angle is 175 degrees.

    Specification
    LED Strip Type: Diffuse Reflection Lens LED Module Lights
    Wire Length:    20cm/PCS
    Input Voltage:     DC 24V
    Size:     70mm*70mm
    Power:     6W/PCS
    LED Color:     2700K-6500K CCT
    LED Quantity:     6LEDs/PCS
    Quantity:     20PCS/String
    Cut:     1 Peice/Cut
    Beam Angle:     175°
    CRI:    85+
    Material:    Aluminum
    LED Chip:     3030
    Central Distance:    270mm/10.62in
    Adhesive Backing:     Yes
