    Diffuse Reflections Lens RGBCCT LED Module - Linear Modules with 12 LEDs - 24V - 20-Pack

    $69.99
      (10 Reviews) | Write a review

    Part Number:GYKJLENS-RGBCCT-12X
    Add to Wishlist
    Choose options above to see availability
    checkmark

    Free Shipping

    No minimum purchase required.
    checkmark

    Worry-free Returns

    - 30 day return policy

    Diffuse reflection RGB CCT LED Modules provide even, soft illumination for advertising light boxes, channel letters, sign lighting, and signage lighting. The LED light module offers a spectrum of color and temperature options, which can be adjusted with an intelligent LED controller according to your needs. It can produce millions of color combinations, making it ideal for scenes that require a wide range of color variations.
    Our CCT RGB LED lens module uses high brightness 3030 LED light source, each chip is equipped with an optical lens. The light turns soft and even through the refraction and reflection of the lens, offering a comfortable visual experience. Offering a 175-degree beam, this lensed module light illuminates a wider area than regular module lights, effectively eliminating dark areas and light spots. And the high color rendering index (CRI) allows this modular light to reproduce the color of objects well, suitable for commercial display scenes.
    The LED light modular contains 20 pieces of modules with 12 LED chips on each piece. Each module can be cut into one unit, you can cut different lengths according to your specific needs. Therefore, it is perfect for irregular light boxes or DIY projects. Our LED modules for signage are powered by low voltage, which is safe and stable. In addition, the LED modular lighting uses aluminum substrate with excellent heat dissipation performance, which helps to extend the service life of LEDs.
    A 24V power supply is required when using this diffuse reflective lens LED Module Light.

    Features
    1. 20pcs/string, every peice has 12 3030 LED beads.
    2. The color is RGBCCT.
    3. The PCB size is 100mm*100mm.
    4. The beam angle is 175 degrees.
    5. Can be cut every peice, making it ideal  for adapting to irregular lightboxes.
    6. The wire length between modules is 20cm/ 7.87in.

    Specification
    LED Strip Type: Diffuse Reflection Lens LED Module Lights
    Wire Length:    20cm/PCS
    Input Voltage:     DC 24V
    Size:     100mm*100mm
    Power:     9.84W/PCS
    LED Color:     RGBCCT
    LED Quantity:     12LEDs/PCS
    Quantity:     20PCS/String
    Cut:     1 Peice/Cut
    Beam Angle:     175°
    CRI:    85+
    Material:    Aluminum
    LED Chip:     3030
    Central Distance:    300mm/10.62in
    Adhesive Backing:     Yes
