FUT035S-PLUS MiBoxer 2.4GHz 2 In 1 LED Controller
This multi-featured 2 in 1, 2.4GHz RF receiver from Mi-Light can be controlled wirelessly using a compatible 2.4GHz Mi-Light & Mi-Boxer handsets or wall panel. Pairing and unpairing the handset or wall panel to the receiver is simple and the receiver also features "Push Dimming" which will switch and dim your connected LED strips when a momentary push switch is wired to the receiver.
The receiver / controller can easily be set to control single colour LED strips or dual colour (CCT) LED strips at 12v or 24v DC, the set button on the receiver and associated indicator light will glow red to indicate single colour mode or green to indicate dual colour mode. An excellent feature of these products is the wireless synchronisation which enables multiple receivers to synchronise together wirelessly each forming a MESH network of products. There is no need to have all the receivers within 30m of the controller as the system forms a MESH network so the wireless signal will jump from receiver to receiver providing each unit is within 30m of the preceding receiver.
Note: Walls and other obstructions between the controller and the first receiver in the network or between each receiver may reduce this range.
These superb wireless receiver / controllers can be used for both commercial or domestic installations for 12v or 24v DC LED strips up to a maximum output of 12A.
Other control options are available and the receiver can be paired with a smartphone application or by voice control through your smart speakers. Note: An additional gateway is required for this feature.
For more information on these or any of our Mi-Light / Mi-Boxer range of products please call our technical sales team or contact us by email or live chat on our website.
Key Features:
RF remote control (2.4GHz) & Push Dim
For single colour & dual white adjustable strips
For Mi-Light 2.4GHz RF handsets & wall panels
Smartphone compatible (gateway required)
Smart speaker compatible (gateway required)
Wireless synchronisation between receivers
Adjustable PWM frequency from 250Hz to 16KHz
Compatible with the Mi-Light 100 Zone handset
Easy to pair with handsets & wall panels
Installation Guide:
